Intellinet 506502 convertisseur de support réseau 100 Mbit/s 1310 nm Multimode Noir
Référence : 506502
Intellinet 506502, 100 Mbit/s, IEEE 802.3, IEEE 802.3u, Fast Ethernet, 10,100 Mbit/s, Complète, Demi, 2000 m
56,10 €
HT
67,32 € TTC
The Intellinet Network Solutions Fast Ethernet Media Converter was specifically designed to offer the network designer a device for migration from copper-based Ethernet to Fibre Ethernet. Now migration or expansion of existing networks can be achieved with minimum cost and complexity. The converter is completely transparent to the network so the network performs exactly the way it did before - only now it can support both copper and fibre mediums.
Expands the Size of an Existing Network
Provides fibre connectivity to Ethernet segments, allowing for even further networking expansion between extended workgroups. Also provides building-to-building connectivity without the need for the cost and disruption associated with the installation of additional routers.
Enhances the Distance between Networking Devices
Connecting the converter to fibre segments can further extend distances between networking nodes. This can be achieved by direct connection between the converter and a fibre-based node or networking device.
Cabling Flexibility
Network managers can install fibre cabling anywhere within a network without changing the arrangement of copper-based Ethernet. The compact size of the converter allows it to be easily deployed in any narrow desktop location or to be used in a wall-mount installation. Several converters can be simultaneously installed into a 19"; rack-mountable chassis.
Expands the Size of an Existing Network
Provides fibre connectivity to Ethernet segments, allowing for even further networking expansion between extended workgroups. Also provides building-to-building connectivity without the need for the cost and disruption associated with the installation of additional routers.
Enhances the Distance between Networking Devices
Connecting the converter to fibre segments can further extend distances between networking nodes. This can be achieved by direct connection between the converter and a fibre-based node or networking device.
Cabling Flexibility
Network managers can install fibre cabling anywhere within a network without changing the arrangement of copper-based Ethernet. The compact size of the converter allows it to be easily deployed in any narrow desktop location or to be used in a wall-mount installation. Several converters can be simultaneously installed into a 19"; rack-mountable chassis.
-
Marque
-
Référence506502
-
EAN130766623506502
-
Longueur d'onde1310 nm
-
Adaptateur d'alimentation externeOui
-
Type d'interface EthernetFast Ethernet
-
Diamètres de câbles de ficre pris en charge50/125,62.5/125 µm
-
Entrée DCOui
-
VoyantsLAN, Liaison, Énergie, Statut
-
Taux de transfert de données (maximum)100 Mbit/s
-
Poids500 g
-
Profondeur107 mm
-
Largeur70 mm
-
Hauteur26 mm
-
Type d'emballageBoîte
-
CertificationFCC Class B, CE, UKCA, NDAA
-
Adaptateur secteur fourniOui
-
Matériau du boîtier/corpsMétal
-
Tension d'entrée5 V
-
Manuel d'utilisationOui
-
Code du système harmonisé85176990
-
InterneNon
-
Standards réseauIEEE 802.3, IEEE 802.3u
-
Ports Fibre Channel1
-
Nombre de port ethernet LAN (RJ-45)1
-
Connecteur de fibre optiqueSC
-
Système recto-versoComplète, Demi
-
Structure du mode de fibreMultimode
-
pouvoir Tx (max)-12 dBmW
-
Courant d'entrée1 A
-
LAN Ethernet : taux de transfert des données10,100 Mbit/s
-
pouvoir Tx (min)-22 dBmW
-
Taux d'humidité de fonctionnement10 - 90%
-
Température hors fonctionnement-45 - 80 °C
-
Consommation (max)2,5 W
-
Température d'opération0 - 70 °C
-
Distance de transfert maximale2000 m
-
Auto MDI/MDI-XOui
-
CouleurNoir
-
Technologie de connectivitéAvec fil
-
Sensibilité-30 dBmW
